Raymarine Actuator Control Unit f/Solenoid Contolled Steering Systems & Constant Running Hydraulic Pumps ACU-300

Raymarine Actuator Control Unit f/Solenoid Contolled Steering Systems & Constant Running Hydraulic Pumps ACU-300. Choose the ACU that fits your steering system type. Drive Current Output Maximum continuous 5 Amps at supply voltage Drive Clutch Output No clutch connection Connections Includes the M81105 Rotary Rudder ReferenceSleep switch Power Solenoid drive out / return Ground Nominal supply voltage 12 V or 24 V Operating voltage range 10.8V to 31.2V dc Power Consumption (standby) - Main Power Supply 300 mA (12/24V) Power Consumption (standby) - SeaTalkng Power Supply 20 mA (12V) SeaTalkng LEN (Load Equivalency Number) 1 SeaTalkng Power Out 3 Amp at 12V (fuse protected at 3 Amp) Data Connections SeaTalkng Installation Environment Operating Temperature: -20C to +55C (-4F to +131F) Storage Temperature: -30C to +70C (-22F to +158F) Relative Humidity: MAX 93percent Waterproof rating Drip resistant Dimensions (W x H x D) 285mm x 211.5mm x 64.5mm (11.2 in x 8.3 in x 2.5 in) Weight 2.2kg (4.84lbs) Conformance Europe: 2004/108/EC Australia and New Zealand: C-Tick Compliance Level 2 Specifications for Raymarine ACU-300 Actuator Control Unit f/Solenoid Contolled Steering Systems & Constant Running Hydraulic Pumps: Manufacturer: Raymarine Color: Black Package Contents: Raymarine ACU-300 Actuator Control Unit f/Solenoid Contolled Steering Systems & Constant Running Hydraulic Pumps Raymarine E70139: Actuator Control Unit f/Solenoid Contolled Steering Systems & Constant Running Hydraulic Pumps ACU-300
