Maretron Current Loop Monitor CLM100

Maretron Current Loop Monitor CLM100. Numerous 4-20mA current loop transducers are supported by the CLM100 including transducers for monitoring DC voltage and current flow rate distance linear velocity and acceleration angle angular velocity and acceleration temperature humidity resistance strain gauges force (load cell) pressure decibels and rotational rate. Some typical applications where the CLM100 is used together with a commercial available 4-20mA transducers include machinery monitoring using accelerometers and vibration sensors. Vibration monitoring of pumps motors fans compressors and gear boxes provides an early warning of potential problems resulting in fewer breakdowns and reduced maintenance expenses. Another application example using the CLM100 is shaft speed monitoring. A commercially available 4-20mA rotational rate transducer is coupled to the shaft of interest and the CLM100 converts the transducer data to an RPM that can be read on a compatible NMEA 2000 display. And if you're concerned about the force exerted on a mast stay or perhaps a vessel tow attachment point commercially available clevis pins with a 4-20mA interface can be connected to the CLM100 and the corresponding load monitored using any of Maretron's display products. Specifications for Maretron CLM100 Current Loop Monitor: Manufacturer: Maretron Color: Black Features of Maretron CLM100 Current Loop Monitor Used together with commercially available 4-20mA Current Loop Transducers Converts analog transducer data to digital data (NMEA 2000) Digital data displayed on Maretron Displays Package Contents: Maretron CLM100 Current Loop Monitor Maretron CLM100-01: Current Loop Monitor CLM100
